#41 Roller Chain Sprockets

Raydafon Group's #41 Roller Chain Sprockets deliver reliable power transmission in industrial settings, ensuring smooth operation with durable steel construction. Ideal for engineers and manufacturers, they reduce downtime and boost efficiency, offering superior precision and longevity over standard alternatives. Experience dependable performance and enhanced productivity—trust Raydafon Group for your mechanical needs.

Send Inquiry

Product Description

Our 41 roller chain sprockets are manufactured dimensionally to ANSI B29 Standards and are manufactured from high-strength high-grade steel for optimal wear life and performance, while still being supplied at a budget-friendly cost. A high-quality sprocket is essential to the long-term operation of the chain drive. If sprockets are manufactured out of cheaper and lower-grades of steel the teeth will wear and hook resulting in excessive wear on the 41 roller chain.

#41 A-Plate Sprockets

Sprocket Size	Tooth Count	Type	Outside Diameter	Weight (LBS)
41A15	15	A	5/8	0.28
41A16	16	A	5/8	0.34
41A17	17	A	5/8	0.36
41A18	18	A	5/8	0.44
41A19	19	A	5/8	0.46
41A20	20	A	5/8	0.52
41A21	21	A	5/8	0.60
41A22	22	A	5/8	0.66
41A23	23	A	5/8	0.72
41A24	24	A	5/8	0.82
41A25	25	A	5/8	0.88
41A26	26	A	5/8	0.94
41A27	27	A	5/8	1.00
41A28	28	A	5/8	1.08
41A30	30	A	19/32	1.20
41A32	32	A	19/32	1.44
41A35	35	A	19/32	1.70
41A36	36	A	19/32	1.84
41A40	40	A	23/32	2.22
41A42	42	A	23/32	2.50
41A45	45	A	23/32	2.52
41A48	48	A	23/32	2.92
41A54	54	A	23/32	3.54
41A60	60	A	21/32	4.60
41A70	70	A	23/32	6.22
41A72	72	A	23/32	6.32
41A80	80	A	23/32	8.46
41A84	84	A	23/32	9.12
41A96	96	A	15/16	11.84
41A112	112	A	15/16	15.84

#41 B-Hub Sprockets

Sprocket Size	Tooth Count	Type	Outside Diameter	Stock Bore	Recommend Max. Bore	Hub Diameter	Length Thru Bore	Weight (LBS)
41B6	6	B	1.170	3/8	3/8	21/32	7/8	0.07
41B7	7	B	1.340	1/2	3/8	3/4	7/8	0.10
41B8	8	B	1.510	1/2	1/2	63/64	7/8	0.19
41B9	9	B	1.670	1/2	5/8	1-1/8	7/8	0.20
41B10	10	B	1.840	1/2	3/4	1-1/4	7/8	0.27
41B11	11	B	2.000	1/2	7/8	1-7/16	7/8	0.35
41B12	12	B	2.170	1/2	15/16	1-9/16	7/8	0.44
41B13	13	B	2.330	1/2	1	1-9/16	7/8	0.50
41B14	14	B	2.490	1/2	1-1/4	1-3/4	7/8	0.57
41B15	15	B	2.650	5/8	1-5/16	1-29/32	7/8	0.72
41B16	16	B	2.810	5/8	1-3/8	2-1/16	7/8	0.91
41B17	17	B	2.970	5/8	1-1/2	2-15/64	1	1.09
41B18	18	B	3.140	5/8	1-5/8	2-3/8	1	1.25
41B19	19	B	3.300	5/8	1-3/4	2-15/32	1	1.49
41B20	20	B	3.460	5/8	1-7/8	2-3/4	1	1.64
41B21	21	B	3.620	5/8	1-7/8	2-7/8	1	1.81
41B22	22	B	3.780	5/8	2	3	1	1.93
41B23	23	B	3.940	5/8	2-1/4	3-3/16	1	2.25
41B24	24	B	4.100	5/8	2-1/4	3-1/4	1	2.33
41B25	25	B	4.260	5/8	2-1/4	3-1/4	1	2.46
41B26	26	B	4.420	5/8	2-1/4	3-1/4	1	2.50
41B27	27	B	4.580	5/8	2-1/4	3-1/4	1	2.56
41B28	28	B	4.740	5/8	2-1/4	3-1/4	1	2.64
41B30	30	B	5.060	5/8	2-1/4	3-1/4	1	2.80
41B32	32	B	5.380	5/8	2-1/4	3-1/4	1	2.96
41B35	35	B	5.860	5/8	2-3/8	3-1/4	1	3.12
41B36	36	B	6.020	3/4	2-3/8	3-1/4	1	3.32
41B40	40	B	6.650	3/4	2-3/8	3-1/4	1-1/16	4.06
41B42	42	B	6.970	3/4	2-3/8	3-1/2	1-1/16	4.10
41B45	45	B	7.450	3/4	2-3/8	3-1/2	1-1/16	4.18
41B48	48	B	7.930	3/4	2-3/8	3-1/2	1-1/16	4.92
41B54	54	B	8.880	3/4	2-3/8	3-1/2	1-1/16	5.68
41B60	60	B	9.840	3/4	2-3/8	3-1/2	1-1/16	6.78
41B70	70	B	11.430	3/4	2-3/4	4	1-3/16	9.54
41B72	72	B	11.750	3/4	2-3/4	4	1-3/16	9.64
41B80	80	B	13.030	3/4	2-3/4	4	1-3/16	11.54
41B84	84	B	13.660	1	2-3/4	4	1-3/16	12.20
41B96	96	B	15.570	1	2-3/4	4	1-3/16	14.86
41B112	112	B	18.120		2-3/4	4	1-3/16	19.16
