The SFUD 7/170 worm gear unit is a double reduction worm gear unit that can meet the requirements of slow-speed machinery. Its transmission ratio ranges from 75:1 to 4900:1 and can be used in underdriven, overdriven, and vertical assembly conditions. Our company provides Elecon brand replacement worm reducers that offer high-quality and cost-effective alternatives to the original equipment manufacturer. Please note that our products are replacement parts and not original equipment. If you require original equipment, please contact the original supplier for purchase.
The SFUD 7/170 worm gear unit is a double reduction worm gear unit consisting of two single reduction worm gear units. Its main worm unit is specially designed to be installed as a whole on a standard single worm unit that constitutes the second stage. The entire gear device is compact and sturdy, making it suitable for slow-motion machinery. The transmission ratio range is extensive, from 75:1 to 4900:1. These gear devices are particularly suitable for high torque, slow-speed drive. The worm gear transmission conforms to the BS-721 standard.
The SFUD 7/170 worm gear unit can be used in various applications such as:
Our worm gear unit is suitable for low-speed transmission equipment that requires high torque. Please see the below image for more examples of our worm gear reducer applications.
Equipment installation, use, and maintenance should note the following:
| Possible Issues | Causes | Solutions |
|---|---|---|
| Inadequate lubrication | Low oil levels, incorrect oil type, or clogged oil filters | Check and maintain proper lubrication levels, use the correct oil type, and replace oil filters. |
| Excessive noise and vibration | Worn or damaged gears, misaligned shafts, or imbalanced loads | Replace worn or damaged gears, realign shafts, or balance loads. |
| Overheating | Excessive load or inadequate ventilation | Reduce the load or improve ventilation. |
| Seal leakage | Damaged or worn seals | Replace damaged or worn seals. |
| Shaft breakage | Excessive loads or accidental impact | Reduce the load or prevent accidental impact. |
| Shaft deflection | Excessive loads or misalignment | Reduce the load or realign shafts. |
| Abnormal gear wear | Excessive loads or inadequate lubrication | Reduce the load or maintain proper lubrication levels. |
| Bearing failure | Excessive loads or poor lubrication | Reduce the load or maintain proper lubrication levels. |
Our company provides replacement parts for Elecon brand worm reducers. Our worm gear units offer the following advantages:
Please note that our products are replacement parts and not original equipment. If you require original equipment, please contact the original supplier for purchase. We also welcome customers to provide drawings or samples for custom orders. See the below image for an example of a worm drive motor.
Worm gear units and electric motors are integral components of many power transmission systems. Our company also provides various types of electric motors for sale that are suitable for use with our worm gear reducers. We understand the importance of matching the correct motor to the worm gear unit to ensure optimal performance and reliability. See the below image for an example of some of the electric motors we offer.
Our worm gear reducers and electric motors are designed to work together seamlessly, providing customers with a complete power transmission solution. We have over 20 years of experience in designing, manufacturing, and selling gearboxes, serving customers worldwide with high-quality, energy-efficient, and stable products. Our customers come from various industries, such as equipment, food, car washing, packaging, transmission, automation, solar energy, and more. We are committed to providing the best service, highest product quality, and most competitive prices to our customers. See the below image for a glimpse of our factory.
A: The transmission ratio ranges from 75:1 to 4900:1.
A: The worm gear unit can be used in conveyors, hoists, mixers, cranes, material handling equipment, agitators, pumps, and many other slow-speed transmission equipment that requires high torque.
A: Reduce the load or improve ventilation to prevent overheating.
