| Model | Normal torque(N.m) | Max. intermittent torque(N.m) | Maximum axial force of output shaft(KN) | Maximum radial force at the midpoint of the output shaftn2*h=30000(KN) | Output shaft | Reduction ratio | |||
| EPT-781D | 950 | 2500 | 63 | 17 | 2" hex shaft | 3.54:1 | |||
| * NORMAL INPUT SPEED 1000rpm | |||||||||
| * WITHOUT LUBRICANTS | |||||||||
Applications:
