CMN55G Micro Oil Screw Air Compressor Medium Pressure 3-4Mpa



CMN55G Micro Oil Screw Air Compressor Medium Presuure 3-4Mpa

Advantages of Our micro oil air compressor

1. No Shaft Seal Design, Robust and Durable

Our unique no-shaft seal design eliminates the need for regular replacement. It is invented to be never in contact and never wear out, extending the life of the shaft seal indefinitely even under non-lubricated conditions.

2. Low Energy Consumption

With the world's largest screw design and double pressure cavity host, our compressor provides energy-efficient compression. The volume efficiency is over 95%, making it a truly energy-saving compressor.

3. High Temperature Resistance

Our Micro Oil Air Compressor can operate under various harsh environmental conditions, with an operating temperature range from -20 to 55 degrees Celsius and a continuous operating temperature not exceeding 92 degrees.

4. Oil Content Less Than 2ppm

Our high-efficiency host requires only a small amount of air compressor oil to achieve excellent sealing effect, resulting in an oil content in the produced gas of less than 2ppm.

Structural Features of Our Micro Oil Air Compressor

1. Ultra-Quiet Intake System Design

Our patented ultra-quiet intake system design reduces operational noise, providing a more user-friendly experience.

2. High-Quality Safety Valve and Minimum Pressure Valve

The safety valve and minimum pressure valve of our Micro Oil Air Compressor are of high quality, ensuring safe and efficient operation.

3. Precision Temperature Sensor

The precision temperature sensor in our compressor accurately monitors and controls the operating temperature, ensuring optimal performance and longevity of the machine.

4. Ultra-Quiet Centrifugal Fan

Our ultra-quiet centrifugal fan contributes to the low noise operation of our compressor, making it ideal for use in noise-sensitive environments.

5. Japanese SMC Electromagnetic Control Valve

The Japanese SMC electromagnetic control valve in our compressor ensures reliable and efficient operation.

6. CMN's Patented Control Valve

Our patented control valve, designed and manufactured by CMN, provides precise control over the compressor's operation.

7. High-Quality Touch Screen Control System

Our high-quality touch screen control system allows for easy and efficient operation of the compressor.

Principle of Compressed Air in Our Micro Oil Screw Air Compressor

Our Micro Oil Air Compressor uses a pair of main screws, namely the pressure screw and the rotating screw, to complete the compression process. These screws are usually made of high-strength alloy steel and have precise helical shapes. During the intake process, the helical shape of the pressure screw and rotating screw forms a sealed working chamber between them. As the screws rotate, the working chamber gradually expands, allowing external air to enter the working chamber through the intake port. Once the air enters the working chamber, the rotation of the screw causes the working chamber to gradually shrink. This shrinking gradually increases the compression ratio of the air, thereby increasing the pressure of the air. In this process, the air is compressed and pushed to the outlet of the machine. The compressed air generates heat during the compression process, so a cooling system is needed to reduce the temperature. At the same time, to ensure air quality, the compressed air also needs to be cleaned through a filtration system to remove potential pollutants and particles.

Applications of Micro Oil Air Compressor

air compressor Application">

1. Textile Industry

Many places in the textile industry use oil-free, micro oil low-pressure compressed air.

2. Glass Bottle Manufacturing

Various glass bottles rely on low-pressure screw compressed air for blowing and shaping, saving energy and creating perfect shapes.

3. Chemical Industry

Some processes in the chemical industry, such as pressure filtration and transportation, require compressed air.

4. Cement Transportation

In the process of cement transportation, compressed air can both complete the transportation and prevent cement dust from flying around.

About Our Company

Our company's full range of products has passed German TUV class 0 oil-free certification, CE certification, ISO9001 certification, TS16949 certification. We are the first domestic company to use water for internal cooling and lubrication of high-end screw compressors. We have also pioneered the launch of a two-stage compression high-pressure micro oil screw compressor with a pressure of up to 4.0MPa globally. We have subsequently developed the world's first 4.0MPa pressure oil-free screw compressor and the world's first 1.25MPa pressure oil-free vortex compressor.
