EPW enhancement planetary gearboxes dimensions

Products Type

EPW215

EPW265

EPW315

EPW360

EPW420

Ratio

stages

Nominal output

torque T 2N

Nm

2223

5560

9597

15256

24136

4

1

1715

4540

7854

12500

18621

5

1036

3673

6350

10086

15012

8

2223

5560

9597

15256

24136

16

2

2223

5560

9597

15256

24136

20

1715

4540

7854

12500

18621

25

2223

5560

9597

15256

24136

32

1715

4540

7854

12500

18621

40

1036

3673

6350

10086

15012

64

2223

5560

9597

15256

24136

80

3

2223

5560

9597

15256

24136

100

1715

4540

7854

12500

18621

125

2223

5560

9597

15256

24136

160

1715

4540

7854

12500

18621

200

2223

5560

9597

15256

24136

256

1715

4540

7854

12500

18621

320

1036

3673

6350

10086

15012

512

Emergency stop

Nm

1.5-times of T 2N

Products Type

EPW215

EPW265

EPW315

EPW360

EPW420

stages

轴长 1/2 处为受力点

输出轴转速为 100rpm

无冲击或轻微冲击

寿命 10000h

Frmax

N

9500

13500

20000

23000

26000

Famax

-6500

+6500

-10200

+8300

-12600

+10200

-15500

+12600

-19000

+15500

轴长 1/2 处为受力点

输出轴转速为 50rpm

无冲击或轻微冲击

寿命 10000h

Famax

N

12000

19000

25000

29000

3400

最大轴向力

-8200

+8200

-12000

+10200

-15800

+12000

-19000

+15800

-23500

+19000

Efficiency with full load

%

96

1

94

2

90

3

Average lifetime

h

Weight

Kg

51(60)

97 (115)

147 (182)

230 (273)

320 (365)

1

60 (70)

100 (117)

162 (197)

245 (288)

370 (415)

2

65 (75)

110 (127)

167 (202)

260 (303)

385 (430)

3

Noise

dB(A)

≤ 70

≤ 70

≤ 72

≤ 72

≤ 75

Advised input speed

r/min

2000

2000

1500

1500

1500

Max. input speed

r/min

4000

4000

3000

3000

3000

products type

EPW215

EPW265

EPW315

EPW360

EPW420

stages

1

2

3

1

2

3

1

2

3

1

2

3

1

2

3

D1

flange holes circle

Φ

190

225

265

300

350

D2

installment hole

12- Φ

12

14

14

18

18

D3

output shaft diameter

Φ h7

50

80

90

110

120

D4

shaft root

Φ

60

100

110

125

140

D5

output diameter

Φ h7

160

200

230

250

300

D6

output flange diameter

Φ

215

250

300

350

400

D7

input center bore for motor

Φ H7

114.3

114.3

114.3

180

114.3

114.3

230

180

114.3

250

230

180

300

250

230

D8

input pinion bore

Φ F7

35

35

35

42

35

35

55

42

35

60

55

42

65

60

55

D9

hole circle

Φ

200

200

200

215

200

200

265

215

200

300

265

215

350

300

265

D10

mounting thread depth

4-/8-

M12

M12

M12

M12

M12

M12

M12

M12

M12

M16

M12

M12

M16

M16

M12

D11

body diameter

Φ

215

265

315

360

420

Q1

input flange

Φ

□ 175

□ 175

□ 175

250

□ 175

□ 175

300

250

□ 175

350

300

250

400

350

300

L1

key length

70

90

120

150

180

L2

distance from shaft end

5

10

10

10

15

L3

shaft length from spigot

80

110

140

170

210

L4

shaft length from output

95

130

160

195

235

L5

body length

256.5

304.5

342

412

424.5

472.5

468

549

561.5

525

633

714

580

695

803

L7

overall length

411.5

459.5

497

572

614.5

662.5

663

739

781.5

780

863

939

857

990

1073

L8

spigot depth

10

15

15

20

20

L9

motor location depth

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

6.5

L10

motor shaft length

83.5

83.5

83.5

93.5

83.5

83.5

116.5

93.5

83.5

145

116.5

93.5

144

145

116.5

B1

key width

14

22

25

28

32

H1

key height

53.5

85

95

116

127

Z

orient holes

M12*26

M16*35

M16*35

M16*35

M20*50

H

flange length

17

20

25

30

30

B2

input key slot width

10

10

10

12

10

10

16

12

10

18

16

12

18

18

16

H2

input key slot height

38.3

38.3

38.3

45.3

38.3

38.3

59.3

45.3

38.3

64.4

59.3

45.3

69.4

64.4

59.3
