EPW double shaft planetary gearboxes with foot dimensions
  • EPW double shaft planetary gearboxes with foot dimensionsEPW double shaft planetary gearboxes with foot dimensions

EPW double shaft planetary gearboxes with foot dimensions

Raydafon Group's EPW double shaft planetary gearboxes with foot dimensions deliver unmatched precision and durability for industrial applications, combining robust design with seamless integration for demanding machinery. Ideal for engineers and manufacturers, these gearboxes ensure smooth operation, reduce maintenance needs, and solve complex torque transmission challenges. Stand out with their superior efficiency and custom fit, empowering users to enhance productivity and reliability effortlessly—experience peak performance tailored for your needs.
Send Inquiry
Product Description

EPW double shaft planetary gearboxes with foot dimensions

EPW double shaft planetary gearboxes with foot dimensions


products type

EPW215

EPW265

EPW315

EPW360

EPW420

stages

1

2

3

1

2

3

1

2

3

1

2

3

1

2

3

D1

flange holes circle

Φ

155

155

165

170

155

155

200

170

155

215

200

170

250215200

D2

mounting thread depth

4-/8-

M12

M12

M12

M12

M12

M12

M12

M12

M12

M16

M12

M12

M16

M16

M12

D3

output shaft diameter

Φ h7

38

38

35

48

38

38

60

48

38

70

60

48

80

70

60

D4

shaft root

Φ

50

50

55

60

50

50

80

60

50

85

80

60

100

85

80

D5

output diameter

Φ h7

120

120

130

130

120

120

150

130

120

160

150

130

180

160

150

D6

input flange

Φ

190

190

□ 164

200

190

190

230

200

190

270

230

200

310

270

230

L1

key length

50

50

45

65

50

50

80

65

50

90

80

65

110

90

80

L2

distance from shaft end

5

5

7

7.5

5

5

7.5

7.5

5

10

7.5

7.5

10

10

7.5

L3

shaft length from spigot

60

60

58

80

60

60

95

80

60

110

95

80

130

110

95

L4

shaft length from output

70

70

65

90

70

70

110

90

70

125

110

90

145

125

110

L5

body length

236.5

284.5

282.5

379

399.5

447.5

438

516

536.5

486

598

676

545

656

768

L6

flange length

28.5

28.5

52.5

28

28.5

28.5

30

28

28.5

29

30

28

38

29

30

L7

overall length

420

468

485

612

613

661

723

779

780

815

913

969

943

1025

1123

L8

spigot depth

8

8

5

8

8

8

10

8

8

10

10

8

10

10

10

B1

key width

10

10

10

14

10

10

18

14

10

20

18

14

22

20

18

H1

key height

41

41

38

51.5

41

41

64

51.5

41

74.5

64

51.5

85

74.5

64

Z

orient holes

M10*22

M10*22

M10*22

M12*26

M10*22

M10*22

M12*26

M12*26

M10*22

M16*35

M12*26

M12*26

M16*35

M16*35

M12*26

级数

单位

轴长 1/2 处为受力点 ; 转速为 2000rpm; 无冲击或轻微冲击；寿命 10000h

轴长 1/2 处为受力点 ; 转速为 1000rpm; 无冲击或轻微冲击；寿命 10000h

产品型号

最大径向力

最大轴向力

最大径向力

最大轴向力

EPW215

单级

600

1000

750

1200

双级

600

1000

750

1200

三级

400

700

550

950

EPW265

单级

850

1200

1050

1500

双级

600

1000

750

1200

三级

600

1000

750

1200

EPW315

单级

1200

1600

1500

2000

双级

850

1200

1050

1500

三级

600

1000

750

1200

EPW360

单级

1400

1800

1900

2200

双级

1200

1600

1500

2000

三级

850

1200

1050

1500

EPW420

单级

2000

2400

2500

2800

双级

1400

1800

1900

2200

三级

1200

1600

1500

2000

*For longer motor shafts L6 apEPLies:The measure L6 and L10 will be lengthen by the same amount as the motor shaft.Hornwork 1）i=10hour，D6=φ120；Hornwork 2）i=10hour，L5=178，L7=290。
