High Strength Drive Shaft CV Axle For Honda 44350-HR4-A22 44350-HR4-A21 44220-HR3-A21

High Strength Drive Shaft CV Axle

The High Strength Drive Shaft CV Axle for Honda 44350-HR4-A22 44350-HR4-A21 44220-HR3-A21 is an essential component of a vehicle's drivetrain system. It is responsible for transmitting torque and power from the transmission to the wheels of the vehicle. Made with high-quality 40Cr Steel and a neoprene polychloroprene (CR) boot material, this drive shaft axle kit is designed for durability and long-lasting performance.

Product Features:

• Length: 19 3/8
• Inboard Splines: 20T
• Inboard Spline Diameter: 2 9/16
• Outboard Splines: 26T
• Outboard Spline Diameter: 2 9/16
• Shaft Diameter: 13/16
• Thread Measurement: M20x1.0

Direct Replacement for the Following OEM Part Numbers:

44350-HR4-A22, 44350-HR4-A21, 44220-HR3-A21

Compatibile with the Following Vehicles:

• Honda FourTrax Foreman 500 EPS: 2014-2019
• Honda FourTrax Foreman 500 ES EPS: 2014-2019
• Honda FourTrax Foreman 500 ES: 2014-2019
• Honda FourTrax Foreman 500: 2014-2019
• Honda FourTrax Foreman Rubicon 500 Auto DCT Deluxe EPS: 2015-2016
• Honda FourTrax Foreman Rubicon 500 Auto DCT EPS: 2015-2016
• Honda FourTrax Foreman Rubicon 500 Auto DCT: 2015-2016
• Honda FourTrax Foreman Rubicon 500 Deluxe EPS: 2015-2016
• Honda FourTrax Foreman Rubicon 500 EPS: 2015-2019
• Honda FourTrax Foreman Rubicon 500: 2015-2019
• Honda FourTrax Rancher 420 Auto DCT EPS: 2014-2016
• Honda FourTrax Rancher 420 Auto DCT IRS EPS: 2015-2019
• Honda FourTrax Rancher 420 Auto DCT IRS: 2015-2019
• Honda FourTrax Rancher 420 Auto DCT: 2014-2019
• Honda FourTrax Rancher 420 EPS: 2014-2016
• Honda FourTrax Rancher 420 ES: 2014-2016
• Honda FourTrax Rancher 420: 2014-2019

Drive Shaft Kit Overview:

The Drive Shaft Kit is a crucial part of a vehicle's drivetrain system. It is designed to transfer torque and power from the transmission to the wheels of the vehicle. The High Strength Drive Shaft CV Axle for Honda is an excellent example of a high-quality drive shaft kit designed for durability and long-lasting performance.

Features and Benefits:

• Unique structural design for optimized power transmission
• Made with high-performance 40Cr Steel
• Easy to install and maintain
• Compatible with a wide range of vehicles
• Cost-effective solution for replacing worn-out or damaged drive shafts

How the Drive Shaft Kit Works:

The Drive Shaft Kit consists of several components, including the drive shaft, inboard and outboard splines, and the boot material. The drive shaft is connected to the transmission and rotates as the engine runs. The inboard and outboard splines are designed to grip the grooves on the transmission and wheel hubs, respectively. The boot material protects the joints from dirt, water, and debris.

Drive Shaft Kit Applications:

The Drive Shaft Kit is used in a wide range of vehicles and machinery that require power transmission, including cars, trucks, and agricultural equipment. It is especially important in vehicles that operate in harsh environments or off-road conditions.

Installation:

Proper installation of the Drive Shaft Kit is critical to ensure its optimal performance. It is recommended that a professional mechanic or technician install the kit to ensure that all components are properly aligned and secured.

About Raydafon:

Raydafon is a leading manufacturer of Axle assemblies in China. Our products include Front Drive Shaft, Rear Drive Shaft, Differentials, Drive Shaft Kits, and more. We use state-of-the-art CNC production equipment and automatic assembly equipment to ensure the highest quality standards. Our products are known for their durability, reliability, and affordability. We offer custom design services and welcome customers to send us their specifications and requirements.
