High Strength Front CV Axle Set For Arctic Cat MK1001424

High Strength Front CV Axle Set For Arctic Cat MK1001424

The High Strength Front CV Axle Set is an essential part of the Arctic Cat MK1001424 vehicle. It is designed to transfer power from the engine to the front wheels of the vehicle. This axle set is a heavy-duty replacement for the OEM parts, 1502-440, 0402-179, 1502-441, 0402-779, and 0402-249.

Product Information

• Front Left Length: 16 1/2
• Inboard Splines: 20T
• Inboard Spline Diameter: 2 11/16
• Outboard Splines: 21T
• Outboard Spline Diameter: 2 3/4
• Shaft Diameter: 7/8
• Thread Measurement: M18x1.5

• Front Right Length: 17 11/16
• Inboard Splines: 20T
• Inboard Spline Diameter: 2 11/16
• Outboard Splines: 21T
• Outboard Spline Diameter: 2 3/4
• Shaft Diameter: 7/8
• Thread Measurement: M18x1.5

The High Strength Front CV Axle Set comes with all the necessary hardware for installation.

Compatibility

The High Strength Front CV Axle Set is compatible with the following Arctic Cat vehicles:

• Arctic Cat 250 2X4: 2001
• Arctic Cat 250: 2001
• Arctic Cat 300 2X4: 2001
• Arctic Cat 300: 1998-2001
• Arctic Cat 400 2X4: 2001
• Arctic Cat 400: 2001
• Arctic Cat 500 Automatic Limited: 2001
• Arctic Cat 500 Automatic: 2000-2001
• Arctic Cat 500: 2000-2001

Features and Benefits

The High Strength Front CV Axle Set offers several unique features and benefits:

• Efficient Power Transfer: The High Strength Front CV Axle Set ensures that power is efficiently transferred from the engine to the front wheels of the vehicle.
• Stable Handling: The High Strength Front CV Axle Set provides stable handling and improved vehicle control.
• Compact Design: The High Strength Front CV Axle Set has a compact design, which makes it easy to install and maintain.
• Wide Adaptability: The High Strength Front CV Axle Set is compatible with a wide range of Arctic Cat vehicles.
• Cost-Effective: The High Strength Front CV Axle Set is a cost-effective replacement for the OEM parts, 1502-440, 0402-179, 1502-441, 0402-779, and 0402-249.
• Easy Maintenance: The High Strength Front CV Axle Set is easy to maintain and requires minimal upkeep.

Working Principle

The Front Drive Shaft, or Front CV Axle, is an essential component in a vehicle's drivetrain system. The Front Drive Shaft is responsible for transferring power from the engine to the front wheels of the vehicle.

The Front Drive Shaft typically consists of several main components, including the shaft, inboard and outboard splines, and joints. The shaft is the primary component that transfers power from the engine to the wheels. The inboard and outboard splines allow the Front Drive Shaft to connect to other components in the drivetrain system. The joints, or CV joints, allow the shaft to move and bend while still transmitting power.

The Front Drive Shaft works by transferring rotational power from the engine to the wheels. As the engine rotates, it creates a twisting force, or torque, which is transferred through the Front Drive Shaft to the wheels. The joints on the Front Drive Shaft allow the shaft to move and bend as the vehicle moves over uneven terrain, while still transmitting power to the wheels.

The material selection of the Front Drive Shaft can have a significant impact on its performance. The Front Drive Shaft must be able to withstand high levels of torque, stress, and vibration. Materials such as steel, aluminum, or carbon fiber are commonly used in the construction of Front Drive Shafts.

Regular maintenance and upkeep are essential to ensuring the Front Drive Shaft's longevity and performance. The Front Drive Shaft should be inspected regularly for signs of damage, wear, or corrosion. Lubrication of the joints is necessary to ensure smooth operation and avoid premature failure.

Applications

The Front Drive Shaft is used in a wide range of vehicles, including SUVs, trucks, and off-road vehicles. The Front Drive Shaft is particularly important in vehicles that have a four-wheel drive or all-wheel drive system, as it is responsible for transferring power to the front wheels.

Company Information

Raydafon is a leading manufacturer in the Chinese Axle assembly market. Our product line includes Front Drive Shafts, Rear Drive Shafts, Differentials, Drive Shaft Kits, and more. We utilize state-of-the-art automated production and assembly equipment to ensure the highest quality products and services for our customers.

Our products are competitively priced and backed by our commitment to customer satisfaction. We offer customized solutions to meet our customers' specific needs and requirements. Contact us today to learn more about our products and services.
