Tractor 3-Point Mounted Flail Mower for Shred Grass and Straw AGL Series

[embed]https://youtu.be/uV9sIx16M9o[/embed]

Tractor 3-Point Mounted Flail Mower for Shred Grass and Straw AGL Series

This flail mower is able to shred grass, straw and branches with higher coverage, and the shredding effect is more delicate. It can easily adjust the stubble height, and can shred grass roots. It also has a number of operational safety protection mechanisms and self-adjusting balance. It has hydraulic control of slide and flip to change mowing position. It reaches under branches, enters ditches, works on roadsides and other places where tractors are not suitable or cannot drive safely. The AGL Hydraulic Side Offset Moveable Flail Mower is a powerful and versatile agricultural machine designed for efficiently cutting and mulching vegetation in various applications. This innovative piece of equipment combines the functionality of a traditional flail mower with the added benefit of hydraulic side offset capabilities. The primary purpose of the AGL Hydraulic Side Offset Moveable Flail Mower is to maintain and manage grassy areas, fields, orchards, vineyards, and road verges. It is commonly used by farmers, groundskeepers, landscaping professionals, and municipal maintenance crews. One of the standout features of this flail mower is its hydraulic side offset mechanism. It allows the operator to adjust the position of the mower deck to the left or right side of the tractor, providing extended reach and enhanced maneuverability. The side offset function enables the operator to mow around obstacles such as trees, fences, or posts without having to reposition the entire tractor. The mower is equipped with a robust cutting system consisting of a series of high-strength flail blades. These blades are designed to rotate at high speeds, effectively cutting and shredding vegetation into fine mulch. The mulching action offers several benefits, including faster decomposition of cut material, improved nutrient recycling, and reduced fire hazards. The AGL Hydraulic Side Offset Moveable Flail Mower is typically powered by the power take-off (PTO) of a tractor. It connects to the tractor's PTO shaft and utilizes the tractor's hydraulic system to control the side offset function. The mower's cutting height can be adjusted to suit different terrain and cutting requirements, ensuring optimal results in various conditions.

Specifications of the AGL Series Flail Mower

Models	Working Width	PTO Input Seed	Hammer Blades	"Y" Grass Blades	Rotor Seed	Required HP	Shipped Weight	Overall Dimensions
	mm	rpm	N.	N.	rpm	hp	Kg	mm
AGL120	1150	540	18	36	2160	35-60	303	1350*800*750
AGL140	1350	540	22	44	2160	40-70	318	1550*800*750
AGL160	1550	540	24	48	2160	45-80	336	1750*800*750
AGL180	1750	540	28	56	2160	60-90	355	1950*800*750

Advantages of the AGL Hydraulic Side Offset Moveable Flail Mower

The AGL Hydraulic Side Offset Moveable Flail Mower offers several advantages that make it a valuable tool for agricultural and landscaping purposes. Here are some key advantages of this mower: 1. Enhanced Maneuverability: The hydraulic side offset feature allows the operator to adjust the position of the mower deck to the left or right side of the tractor. This provides increased maneuverability, making it easier to mow around obstacles such as trees, fences, and posts without the need to reposition the entire tractor. It saves time and effort while ensuring precise cutting in tight spaces. 2. Versatile Cutting Capabilities: The flail mower's cutting system consists of high-strength flail blades that rotate at high speeds. This design allows the mower to effectively cut and mulch a wide range of vegetation, including grass, weeds, brush, and small branches. It can handle diverse terrains and vegetation types, making it suitable for various applications such as fields, orchards, vineyards, and road verges. 3. Efficient Mulching: The flail blades of the mower shred the cut vegetation into fine mulch. This mulching action offers several benefits. Firstly, it promotes faster decomposition of the cut material, contributing to the overall health of the soil. Secondly, the mulch acts as a protective layer, helping to retain moisture, control weed growth, and regulate soil temperature. Additionally, the mulched material can be left on the ground as natural fertilizer, minimizing waste and promoting nutrient recycling. 4. Time and Cost Savings: The AGL Hydraulic Side Offset Moveable Flail Mower enables efficient and quick mowing operations. The hydraulic side offset function eliminates the need for manual repositioning of the tractor when navigating obstacles, saving time and effort. The mulching action reduces the need for separate processes such as collecting and disposing of cut vegetation or applying additional fertilizers. These time and cost-saving features make the mower a valuable asset for agricultural and landscaping professionals. 5. Operator Safety and Comfort: The mower is designed with safety features to ensure operator protection. These may include protective covers to prevent debris from being thrown, safety chains to secure the mower to the tractor, and automatic blade shut-off systems to prevent accidents. Additionally, the hydraulic side offset feature reduces operator fatigue by simplifying maneuvering and minimizing physical strain.

How Does the AGL Hydraulic Side Offset Moveable Flail Mower Work?

The AGL Hydraulic Side Offset Moveable Flail Mower is a sophisticated piece of agricultural and landscaping equipment designed for efficient vegetation management. Its operational mechanism is built around several key features that allow it to handle a wide range of vegetation types, from grass to small bushes and undergrowth. Here's how it works: 1. Hydraulic Side Offset Mechanism

• The mower is equipped with a hydraulic system that allows the mowing deck to move laterally (side to side), independent of the tractor's direct line of travel. This is particularly useful for cutting grass and other vegetation around obstacles (like trees, posts, and edges) without the need to maneuver the tractor too close to these objects. The operator can adjust the side offset hydraulically from the tractor's cabin, enhancing the mower's flexibility and reach.

2. Flail Cutting System

• At the heart of the mower is its flail cutting system, which consists of a rotating drum or shaft equipped with multiple flails (or blades). These flails are usually made of heavy-duty steel and are hinged or attached in a way that allows them to swing freely.
• As the drum spins at high speed, the centrifugal force extends the flails outward, where they cut the vegetation through a combination of impact and a scissoring action. This system is capable of cutting through grass, thicker weeds, and small woody material, making clean cuts without pulling or tearing the plants.

3. Adjustable Cutting Height

• The mower's cutting height can be adjusted to suit the specific needs of the terrain and the type of vegetation being managed. This adjustment is often achieved through skids or wheels attached to the mower, allowing for precision control over the height of the cut, ranging from close to the ground for a fine lawn finish to higher settings for rougher undergrowth or brush.

4. Durability and Safety Features

• The AGL mower is built with durability in mind, featuring a robust construction that can withstand the rigors of heavy-duty use. Safety features include guards and shields that protect the operator from flying debris and reduce the risk of accidents.

5. Power Take-Off (PTO) Drive

• The mower is powered by the tractor's PTO, which transfers engine power to the mower's cutting mechanism. This direct-drive system ensures efficient power use and consistent performance across various types of vegetation and terrain.

Operation Process

1. Attachment: The mower is attached to the tractor's three-point hitch and connected to the PTO shaft.
2. Adjustment: The operator adjusts the side offset and cutting height according to the specific needs of the job.
3. Mowing: As the tractor moves forward, the PTO drives the flail drum, spinning the flails to cut the vegetation. The hydraulic side offset can be adjusted on the go to maneuver around obstacles effectively.
4. Disposal of Cut Material: The cut vegetation is typically distributed evenly across the mowed area, where it can decompose and return nutrients to the soil.

Applications of AGL Hydraulic Side Offset Moveable Flail Mower

The AGL Hydraulic Side Offset Moveable Flail Mower, with its unique features and capabilities, serves a wide range of applications in agriculture, landscaping, and land management. Its versatility and efficiency make it suitable for various tasks, from routine maintenance to specific vegetation management challenges. Here are some of the key applications of this equipment: (1) Orchard and Vineyard Management: The hydraulic side offset feature allows for precise trimming around trees, vines, and posts without damaging the plants. It's ideal for maintaining the undergrowth in orchards and vineyards, helping to control weeds and manage ground cover to promote healthy growth of fruit and vine crops. (2) Roadside and Ditch Maintenance: This mower excels at managing roadside vegetation and clearing ditches. Its ability to move laterally ensures a clean cut along roadsides, verges, and ditches, maintaining clear visibility for drivers and ensuring proper drainage alongside roads. (3) Pasture and Field Maintenance: For agricultural fields and pastures, the flail mower can efficiently manage grasslands, control invasive species, and maintain fodder crops. The quality cut promotes regrowth, enhances pasture quality, and can prevent the spread of diseases among crop plants. (4) Landscaping and Park Maintenance: In public parks and large private estates, the AGL mower provides an effective solution for maintaining lawns, clearing underbrush, and managing areas around walking paths and recreational spaces. Its precision and quality of cut ensure that these areas remain aesthetically pleasing and safe for public use. (5) Brush and Undergrowth Clearing: The mower is capable of handling thicker vegetation, including brush and undergrowth, making it suitable for clearing overgrown areas, preparing land for planting, or managing firebreaks to prevent the spread of wildfires.

Why Choose Raydafon's Flail Mower?
