| Model | Normal torque(N.m) | Max. intermittent torque(N.m) | Maximum axial force of output shaft(KN) | Maximum radial force at the midpoint of the output shaftn2*h=30000(KN) | Output shaft | Reduction ratio | |||
| EPT-882E | 3400 | 7500 | 81 | 25 | 2" hex shaft | 5.06:1 | |||
| * MAX. INPUT SPEED 3000rpm | |||||||||
| * INPUT MOTOR: SAE C FLANGE, DP12/24, Z17, 4 HOLES | |||||||||
| * WITHOUT LUBRICANTS | |||||||||
| * ONLY WITH PRIMER, WITHOU TOP COAT | |||||||||
| * OUTPUT SHAFT DOWN MOUNTED | |||||||||
