Chinese Large Power Direct Driven Screw Air Compressor (SCR300I Series)

Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location: United Kingdom, United States, Thailand, Argentina, Sri Lanka, South Africa, Ukraine, Uzbekistan, Japan
Condition: New
Type: Screw
Configuration: Stationary
Power Source: AC POWER
Lubrication Style: Lubricated
Mute: Yes
Model Number: SCRSCR300I-7, SCR300I-8, SCR300I-10
Voltage: 380(400,415)V/50Hz/3Phase, 220V/60HZ/3P
Dimension(L*W*H): 2460*1620*1692
Weight: 4000kg
Warranty: 1 Year
Working Pressure: 7 bar, 8 bar, 10 bar
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Marketing Type: New Product 2020
Warranty of core components: 5 years
Core Components: PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox
Gas Type: Air
After-sales Service Provided: Overseas service center available
Application: Air Power
High Quality: Good Performance
Exquisite Workmanship: 727 m3/H
Drive Mode: Electric
Color: 65-110 m3/MIN
Product name: SCR125II
Cooling method: Air Cooling
Operating Ambient Temp: 1-45℃ {28.8℉-113℉}
Name: Air Compressor
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location: United Kingdom, United States, Thailand, Argentina, Sri Lanka, South Africa, Ukraine, Uzbekistan, Japan
Warranty: 1 Year
Working Pressure: 7 bar, 8 bar, 10 bar
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Marketing Type: New Product 2020
Warranty of core components: 5 years
Core Components: PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox
Gas Type: Air
Condition: New
Type: Screw
Configuration: Stationary
Power Source: AC POWER
Lubrication Style: Lubricated
Mute: Yes
Model Number: SCRSCR300I-7, SCR300I-8, SCR300I-10
Voltage: 380(400,415)V/50Hz/3Phase, 220V/60HZ/3P
Dimension(L*W*H): 2460*1620*1692
Weight: 4000kg
After-sales Service Provided: Overseas service center available
Application: Air Power
High Quality: Good Performance
Exquisite Workmanship: 727 m3/H
Drive Mode: Electric
Color: 65-110 m3/MIN
Product name: SCR125II
Cooling method: Air Cooling
Operating Ambient Temp: 1-45℃ {28.8℉-113℉}
Name: Air Compressor
Port: SHANGHAI


Product Technical Description

Model :	Large Power Screw Air Compressor (II series)
Type:	Large Power Screw Air Compressor
Voltage:	380V/50HZ/3P, 220V/60HZ/3P, 400V/50HZ/3P, 415V/50HZ/3P or Customer′s Requirements
Working Pressure:	7~12.5 bar
Installed Motor Power:	90KW~400KW
Capacity:	12.5~74 m3/min
Color:	Blue
Driven Method:	Direct Driven
Trademark:	SCR
Transport Package:	Standard Wooden Packing
Available Certificate:	CE, ISO, UL, ASME, GHOST
Origin:	Shanghai, China
application:	Casting , Metal , Plastic , Rubber

Product Features
German high quality centrifugal fanGerman ROSENBERG's newest centrifugal fans, big cooling air volume, stable and uniformair pressure , full use of the heat dissipation area, good cooling effect. Totally conquer the problem of big horse power air cooling type compressors poor cooling effect problems.

High quality air inlet valve
SCR use a high quality imported inlet valve. SCR have adopted this technology because when the machine unloads the device will automatically adjust the exhaust pressure. Compared with similar products this greatly reduces the unload power, also reduces the bearing load at the same time, and improving the bearing service life.

American High quality air filter system
The Donaldson air filter adopts a nano coating on the filter surface with an innovative filter construc-tion. The filter has a low pressure drop which reduc-es energy consumption. Compared with traditional filters it has a higher dust capacity and lower flow resistance.

High quality high efficiency specialized motor
High Efficiency all closed air cooling air compressor specialized motor. Protection grade IP55 Optional , insulation grade F, class B temperature rise, can prevent dust and moisture into the motor. SKF bearing can ensure long-term continuous trouble-free operation.

1.Direct driven airend,high reliability 2.Centrifugal fan coolin system 3.Siemens core control components (1)Famous Siemens electrical appliances are used. (2)The screw compressor has a self-owned PLC integrated function. (3)Intrlligent PLC realize automatically control. 4.Germany KTR coupling

Model		SCR300I-8	SCR300I-10
Capacity/Pressure(m3/min,/BAR)		38.4/8	33.3/10
TEFC Motor	Power(KW)	220KW(300H.P)
	Speed(r/min)	2975
	Starting way	Star-Delta
	Volt(V)	380/400/415(220)
	Motor safety grade	IP54
	Motor isolation grade	F
Electrical Supply		380(400,415)V/50Hz/3Phase, 220V/60HZ/3P
Outlet Temperature(ºC)		≤ Environment Temperature+10ºC
Driven way		Direct Driven
Noise level at 1 meter		84±3dB(A)
Cooling method		Air cooling
Oil content		≤3 ppm
Outlet Connection		DN100
Dimension	Length(mm)	3000
	Width(mm)	2050
	Height(mm)	2097
Weight(KG)		5000

Product Categories

Advantages

	Professional online consultant to solve your question about compressor system.
	Free site design consultant, and energy saving solution to help you save operation cost.
	Negotiable technican available to service machinery overseas.
	Online professional after-service until solve the problem.
	1 year warranty after commissioning or 16months against shipping date, it depends on which one come firstly for the whole machine (except maintenance consumables).
	A sufficient number of spare parts are available, make sure the good after service.

Application
About SCR

1989 Start Sells of Screw Compressor 2008 Establish Shanghai Globe Screw Compressor Technology focus on airend technology through technology cooperation with Germany. Start to use ERP system to realize the management of company.Establish SCR Oversea department. 2010 Get UL certificate, start to sell in US.Export oil free screw compressor to Spain. 2015 Promotion of oil cooling PM compressor, two stage compressor. Export oil free compressor to UK, US etc. Export to more than 55countries around the world. 2018 Jan, 1st, Joint Venture with Japan Anest Iwata to have better future development.

2002 Establish SCR factory in Jinshan Area. Start to assemble screw compressor through cooperation with Germany Company.Get ISO9001 Certificate. 2009 Attend Germany Hannover Mess, Get CE certificate, start to sell in Europen market. 2013 Export low pressure compressor.Start sales of Oil free scroll compressor. 2016 EPM, Low pressure PM compressor be published.10-20HP compact PM compressor be published.Industrial 4.0 start to be used in China market.

FAQ

1 What trade terms do we provide? What kind of settlement currency do we offer?

Trade term :CIF ,CFR ,FOB,Ex-Works As far Our business traded in Dollars ,Euros and RMB .

2 How long is our delivery?

Our standard delivery time is 30-40 days after confirmation order & receiving recipets for standard compressors, for the other non standard requirement will be discussed case by case.

3 What is the voltage of the compressor?

The available voltage include 380V/50HZ/3Phase, 400V/50HZ/3P, 415V/50HZ/3P, 220V/60HZ/3P, 380V/60HZ/3P, 440V/60HZ/3P. At the same time we provide other voltage according to customer requirement.

4 Can our compressor run in high temperature environment? What is the working temperature range for our machine?

Yes ,our machine would run in high temperature environment ,until now our products have been sold to many countries which would meet high temperature in summer ,such like Iraq, Saudi Arabia, Egypt, Algeria, etc. Work temperature range :1-45 ℃(33.8℉-113℉)

5 What’s the min. Order requirement ?

Min. Order requirement is 1PCS.

If you are interested in any of our products,please feel free to contact us.We are looking forward to cooperating,growing and developing with you sincerely.
