Compact Hay Balers for Compact Tractors

Our compact hay balers are ideal for compact tractors. They are round balers with an operating speed of 3-10km/h, and come in new condition. The model numbers are RXYK0850 and RXYK0870. These balers are perfect for picking up and baling grass, alfalfa, wheat, rice straw, and more. With dimensions of 1300x1300x1350mm and a weight of 425 kg, they are compact yet robust. They come with a two-year warranty and are certified by ISO and CE. Attached with a twine rope, they require a matched power of 20-50HP. With a pickup width of 80cm, these green balers are perfect for your agricultural needs.

Advantages of Our Compact Hay Balers

1. Compact and Efficient: The compact design makes it easy to maneuver, especially in small fields. Despite its size, it provides optimal efficiency in baling operations.
2. Powerful: With a matched power requirement of 20-50HP, these balers provide strong performance for superior baling.
3. Wide Application: These balers can pick up and bale various types of crops including grass, alfalfa, wheat, and rice straw.
4. Quality Assurance: These balers are backed by a two-year warranty and certified by ISO and CE, ensuring reliability and quality.
5. Easy to Use: With an operating speed of 3-10km/h and a pickup width of 80cm, these balers are convenient and easy to operate.
6. Safe and Secure: These balers do not provide overseas after-sales service, ensuring your safety and security while using the product.

Applications of Our Compact Hay Balers

1. Agriculture: These balers are ideal for various agricultural applications, such as baling hay, grass, and straw.
2. Animal Feeding: The bales produced by these balers can be used as feed for livestock.
3. Silage Making: These balers can also be used for making silage, a type of animal feed made from green foliage crops.
4. Composting: The bales can also be used for composting, providing a source of nutrients for your crops.
5. Straw Baling: These balers are perfect for baling straw, which can be used for various purposes such as bedding for animals or mulch for gardens.

6. Waste Management: These balers can also be used to compact and bale agricultural waste for easier handling and disposal.

How Does the Tractor Mounted Mini Hay Round Baler Work?

1. Preparing the tractor: Before you start, ensure that the tractor is properly equipped with the necessary power take-off (PTO) shaft and hydraulic connections to operate the baler. The PTO transfers power from the tractor to the baler, while the hydraulic connections control various functions of the baler.
2. Hitching the baler: The baler is attached to the tractor's three-point hitch or other compatible attachment mechanism. The baler must be securely attached to the tractor to ensure a firm and stable connection.
3. Adjusting settings: Based on the desired bale size, density, and other factors, you can set the appropriate baling parameters. These settings may include bale diameter, bale weight, twine tension, and bale density.
4. Operating the pickup attachment: The pickup attachment of the baler is lowered onto the ground using the tractor's hydraulic controls. The pickup attachment consists of rotating tines or belts that gather the loose hay or straw from the ground and feed it into the baling chamber.
5. Bale formation: As the pickup attachment collects the material, it is conveyed into the baling chamber of the baler. Inside the chamber, the material is compressed and formed into a round bale by a combination of belts and rollers. The belts rotate and wrap around the bale, ensuring it remains intact.
6. Bale ejection: Once the bale reaches the desired size and density, it is ejected from the baling chamber and released onto the ground. Some mini hay round balers may have an automatic bale ejection mechanism, while others require manual assistance to remove the bale from the chamber.

How to Install the Mini Hay Round Baler to Tractor?

1. Read the Manuals: Start by reading the operator's manuals for both the tractor and the mini hay round baler. These manuals will provide specific instructions for attaching and operating the equipment, as well as any safety precautions you need to follow.
2. Position the Tractor and Baler: Position the tractor close to the baler so that the PTO shaft on the tractor aligns with the PTO input shaft on the baler. Make sure the ground is level to avoid any unnecessary stress on the equipment during the connection process.
3. Attach the Baler to the Tractor: If your baler attaches via a three-point hitch, raise the hitch on the tractor and align the hitch arms with the mounting points on the baler. Secure the pins through the arms into the baler's mounting points and attach the top link.
4. Connect the PTO Shaft: Slide the PTO shaft from the baler onto the PTO stub on the tractor. Ensure it locks into place; you should hear a click or be able to see that the locking mechanism is engaged.
5. Connect Hydraulics (If Applicable): If the baler requires hydraulic connections to operate, connect the hydraulic hoses from the baler to the tractor's hydraulic outputs. Ensure the connections are secure and the hoses are not kinked or under strain.
6. Test the connections: Before operating the baler, check all the connections, including the hitching mechanism, hydraulic hoses, and PTO shaft, to ensure they are secure and properly fitted.

Maintenance of the Mini Hay Round Baler

Proper maintenance of a mini hay round baler is essential to ensure its optimal performance, longevity, and safety. Here are some key maintenance tasks to consider:

1. Regular cleaning: After each use, clean the baler thoroughly to remove any accumulated debris, hay, or straw. Pay attention to the pickup attachment, baling chamber, belts, and rollers. Use compressed air, brushes, or water (if applicable) to remove stubborn residue.
2. Lubrication: Check the baler's lubrication points and follow the manufacturer's recommendations for lubrication intervals. Apply the appropriate lubricants to the specified areas such as bearings, chains, sprockets, and pivot points.
3. Roller inspection: Inspect the rollers for any signs of damage, misalignment, or excessive wear. Check for loose or missing bolts and ensure that the rollers are clean and free from debris.
4. Twine or net wrap system: If your baler uses twine or net wrap for bale tying, inspect the twine or net wrap system regularly. Check for proper tension, functioning of the twine arms or net wrap mechanism, and any signs of wear or damage.
5. PTO maintenance: If the baler is powered by the tractor's power take-off (PTO), inspect the PTO shaft regularly for any signs of wear, damage, or loose connections. Keep the PTO shaft properly lubricated and replace any worn or damaged components.
6. Check hydraulic system: If your baler has a hydraulic system, inspect the hoses, fittings, and cylinders for leaks, damage, or signs of wear. Ensure that all connections are tight and secure.

Why Choose Raydafon's Mini Hay Round Baler for Agricultural?

Raydafon Agricultural Machinery Co., Ltd. has been engaged in the research and development of agricultural machinery for several years. Our company boasts more than 100 employees, among which, there are 20 technical staff and five senior R&D personnel. We have abundant financial resources and two advanced casting, forging, machining, heat treatment, and lacquering production lines, and we use CAD computer-aided design system. Our production technology is strong and the equipment is advanced, including lathing, milling, planing, stamping, cutting plate, and electric welding. We have accumulated more than ten years of experience in production.

Our Commitment to Quality and Service

We are committed to providing high-quality products and excellent customer service. Our compact hay balers are manufactured with strict quality control procedures to ensure that they meet or exceed industry standards. We are proud to say that our products have earned international certifications such as ISO and CE.

In addition to quality products, we also offer customized services to meet the unique needs of our customers. Our professional team can provide tailored solutions based on your specific requirements for compact hay balers.

We understand that after-sales service is equally important as the quality of the product itself. Therefore, we offer comprehensive after-sales services to our customers. Our dedicated team of technicians is always ready to help with any issues or concerns you may have about our compact hay balers.
