Planetary Gearbox for Soil compactors

• Modular design, combined according to customer requirement
• Heavy bearing, Design for heavy-duty Application
• Hardened gearing, long life with high reliability
• Low-speed shaft design

DATA SHEET

Torque range	1000 … 540000 Nm	Input	IEC Flange
Mechanical rating (n1 = 1500 min-1)	up to 200kW		Electric motor
Gear ratios	12.67 … 50.9		Solid input shaft with or without fan cooling – inch or metric dims.
Gear unit versions	In line	Applicable AC motors	Integral motors and brake motors
			IEC-normalized motors and brake motors
Mounting type	Foot		Single and dual-speed motors
	Flange mounted	Main brake features	DC and AC supply
	Torque-arm		Faster brake reaction through an electronically controlled rectifier
Output shaft options	Solid shaft	Main motor options	Thermistors and thermostat sensors
	Splined shaft		Independent forced cooling
	Female splined shaft		Line driver and push-pull incremental encoder
	Hollow shaft with shrink disc



 planetary gearbox torque sheet with models



Gear unit size	200	201	240	241	280	281	353/354	355	400	401
Normal output torqueT2N[Nm]	1500	2000	3500	4000	4300	7300	13000	16000	20000	23000
Gear unit size	428	429	445	446	510	542	543	695	810	885
Normal output torqueT2N[Nm]	26000	30000	32000	43000	63000	75000	100000	150000	300000	420000
