Max output torque | 300 N.M |
Rated input speed | 4,000 rpm |
Ratio | 10 |
Backlash | ≤5 arcmin |
Weight | 3.9 KG |
Warranty | 18 months |
Noise | ≤ 60 dB |
Max.Radial Force | 3250N |
Max.Axial Force | 1300N |
Gear material | 20CrMnTi Alloy Steel |
Gear precision | DIN6 |
Gear design | Helical gear |
Gear Surface Hardness | 900Hv |
Gear Heat Treatment | Carbonitriding |
Quality Assurance | 1 year |
Service life | 20,000 hours |
Working Temp | -15℃~90℃ |
Mounting Position | Any |
Brand of Bearing | NSK |
Brand of Oil Seal | SKF |
Efficiency | 1 stage≥96%,2 stage ≥94% |
Lubrication | Synthetic Lubricating Grease |
Degree of Protection | IP65 |
Mounting Position | Any Direction |
