Replacement of Walterscheid pto shaft Replacement - W300E 1010mm Profile pair 0v/1

Replacement of Walterscheid Standard PTO shaft

Further information

Universal joint A profile (mm):

27 x 746

Universal joint B profile (mm):

27 x 746

Size:

300E

Tractor version:

1 3/86 splines

Implement version:

1 3/86 splines

(mm):

1010

Profile:

With lemon profile

Locking system:

Push-pull lock/push-pull lock

Profile pair:

0v/1

Guard version:

SD 15

Max. speed (1/min.):

540

Lock:

AZG/ASGE

Type:

W

A (profile):

1 3/86 splines

B (profile):

1 3/86 splines

Additional information:

Operating instructions included

PS/kW(1000 / 540 U/min.):

44 / 28

Weight:

12.43?kg

Service-Center form:

Click here

To be found in category:

Standard PTO shafts & drive technologySearch filters: Standard PTO shaftsStandard Standard PTO shafts

Part no.: 395800013

About the PTO Shaft

Power Take-Off (PTO) shafts are critical components in many types of machinery. They transfer the power from the engine to the equipment that the engine is driving. Here are five key features of PTO shafts:

1. Durability: They're designed to withstand tough working conditions.
2. Versatility: They can be used with various types of machinery.
3. High performance: They ensure efficient power transmission.
4. Safety features: They often include safety guards to protect the user.
5. Customizable: They can be tailored to meet specific requirements.

Our PTO Shaft

We manufacture PTO shafts that match the dimensions and installation methods of Replacement of Walterscheid's models. This means they can be used as perfect replacements. Our PTO shafts are made from high-quality materials to ensure durability and performance.

Choosing the Right PTO Shaft

Choosing the right PTO shaft involves considering several parameters. These include:

1. 1. Length: This is the distance between the transmission device and the receiving device.
   2. Rated Power: This refers to the maximum power that the PTO shaft can handle.
   3. Shaft and Connection Method: These depend on the specific requirements of the machinery.
   4. Torque Transmission Capacity: This is the maximum torque that the PTO shaft can transmit.
   5. Environmental Requirements: These include factors like the need for a protective cover sealing performance and durability.
   6. Safety Features: These could include reliable anti-jamming devices and anti-jamming pins.
   7. Compatibility: The PTO shaft should be compatible with the machinery it's being used with.
   8. Certification: Certifications like CE certification indicate that the PTO shaft meets certain standards.

Importance of CE Certification

CE certification signifies that a PTO shaft complies with relevant regulations and standards of the European Union. This ensures that the design manufacture and use of the PTO shaft meet the requirements of the European market providing a basic safety guarantee. Selling a PTO shaft in the European market requires CE certification. CE certification provides reliable assurance of the safety performance of the PTO shaft. A PTO shaft with CE certification conveys confidence in the quality and safety of the product.

Our Certifications

Our PTO shafts have received CE TS/16949 and ISO 9001 certifications. This attests to their quality and safety.

PTO Shaft Structure

A PTO shaft consists of several parts. These include the housing drive shaft universal joint protective cover and connectors. Each part is made from high-quality materials to ensure durability and performance. We also sell individual parts for those who need them.

PTO Shaft Applications

PTO shafts have a wide range of applications. These include:

1. Agricultural machinery: PTO shafts are commonly used to connect tractors to agricultural equipment like mowers harvesters straWcrushers sprayers mixers etc.
2. Industrial equipment: PTO shafts are used to drive various rotating equipment like pumps generators centrifuges mixers etc.
3. Transportation equipment: PTO shafts are also used to drive certain transportation equipment like trailers semi-trailers and toWtrucks.
4. Solar systems: PTO shafts are often used to rotate and adjust tracker photovoltaic panels.

Adjusting the Length of a PTO Shaft

Adjusting the length of a PTO shaft involves several steps:

1. 1. Remove the plastic protective cover.

   1. shorten the inner and outer tubes according to the required length. both tubes should be shortened by the same length at a time.
   2. use a file to remove burrs.
   3. shorten the inner and outer plastic tubes according to the required length. both tubes should be shortened by the same length at a time.
   4. oil the inner steel tube then reinstall the drive shaft plastic protective cover.


   about hzpt group

   hzpt group is a leading player in the pto shaft market in china. we specialize in the development manufacturing and marketing of power output shafts industrial universal joints and automotive transmission shafts. our products enjoy a good reputation among customers in europe the united states asia australia and north america. we offer customization and contract manufacturing services with laser printing of logos. we're among the top three professional oem suppliers for many agricultural machinery factories. we have received ce ts/16949 and iso 9001 certifications. our systematic production equipment and team ensure the quality and delivery of our products. besides we also supply related products like agricultural gearboxes chains sprockets pulleys couplings and agricultural machinery parts. customization based on drawings or samples is welcome.author: miya src="https://hzpt.com/wp-content/uploads/2023/12/00_pto-shaft-11.webp" />
   1. Shorten the inner and outer tubes according to the required length. Both tubes should be shortened by the same length at a time.
   2. Use a file to remove burrs.
   3. Shorten the inner and outer plastic tubes according to the required length. Both tubes should be shortened by the same length at a time.
   4. Oil the inner steel tube then reinstall the drive shaft plastic protective cover.


   About Raydafon Group

   Raydafon Group is a leading player in the PTO Shaft market in China. We specialize in the development manufacturing and marketing of power output shafts industrial universal joints and automotive transmission shafts. Our products enjoy a good reputation among customers in Europe the United States Asia Australia and North America. We offer customization and contract manufacturing services with laser printing of logos. We're among the top three professional OEM suppliers for many agricultural machinery factories. We have received CE TS/16949 and ISO 9001 certifications. Our systematic production equipment and team ensure the quality and delivery of our products. Besides we also supply related products like agricultural gearboxes chains sprockets pulleys couplings and agricultural machinery parts. Customization based on drawings or samples is welcome.
   1. shorten the inner and outer tubes according to the required length. both tubes should be shortened by the same length at a time.
   2. use a file to remove burrs.
   3. shorten the inner and outer plastic tubes according to the required length. both tubes should be shortened by the same length at a time.
   4. oil the inner steel tube then reinstall the drive shaft plastic protective cover.


   about hzpt group

   hzpt group is a leading player in the pto shaft market in china. we specialize in the development manufacturing and marketing of power output shafts industrial universal joints and automotive transmission shafts. our products enjoy a good reputation among customers in europe the united states asia australia and north america. we offer customization and contract manufacturing services with laser printing of logos. we're among the top three professional oem suppliers for many agricultural machinery factories. we have received ce ts/16949 and iso 9001 certifications. our systematic production equipment and team ensure the quality and delivery of our products. besides we also supply related products like agricultural gearboxes chains sprockets pulleys couplings and agricultural machinery parts. customization based on drawings or samples is welcome.author: miya>
