The TD200 Series High Precision Planetary Gearbox Helical Gear Reducer is a type of gearbox that is used to transmit torque and reduce speed between a motor and a driven machine. The gearbox is also known as the servo motor planetary gearbox and the low backlash planetary gearbox. This gearbox is designed to provide high precision and low backlash, making it ideal for applications where precision positioning is critical. The TD200 Series High Precision Planetary Gearbox Helical Gear Reducer is commonly used in robotics, automation, and other industrial applications.
The High Precision Planetary Gearbox consists of the following components:
The Sun Gear is located at the center of the planetary gearbox and is usually connected to the input shaft or fixed to the housing as a stationary component.
The Planet Gears revolve around the Sun Gear and are supported and maintained in their relative positions by a Planet Carrier. Each Planet Gear meshes with the Sun Gear and the Ring Gear.
The Planet Carrier is a structure with multiple Planet Gear shaft holes, which carries the Planet Gears and allows them to rotate relative to the Sun Gear. The Planet Carrier can serve as an output element or be connected to another shaft to transmit or receive torque.
The Ring Gear/Annulus is a large diameter ring-shaped gear fixed inside the housing with teeth on both the inner and outer surfaces. It meshes with the Planet Gears. In some applications, the Ring Gear/Annulus can also serve as an input or output end.
Bearings in the high-precision planetary gearbox support the input shaft, output shaft, and Planet Carrier to ensure stable rotation and smooth operation between the components.
The Housing is the external framework of the gearbox, which protects the internal components from external environmental influences and provides installation interfaces. Seals ensure that the internal lubricating grease does not leak and prevent dust and water from entering the gearbox.
The working principle of High Precision Planetary Gearbox is explained below:
When power is input to the Sun Gear, it drives the surrounding Planet Gears to rotate. As the Planet Gears mesh with both the Sun Gear and the Ring Gear/Annulus, they also revolve around the center of the Sun Gear with the Planet Carrier. Therefore, the torque input to the Sun Gear is amplified and evenly distributed to the Planet Carrier on the output side via the Planet Gears.
By adjusting the gear ratio of different components, speed conversion between input and output as well as torque amplification can be achieved. Generally, the more Planet Gears or the larger the gear ratio, the more significant the torque amplification effect, but the output speed will also decrease.
In high-precision applications, to ensure accurate position control and minimal mechanical clearance, high-precision planetary gearboxes adopt preloading technology to reduce or eliminate gear clearance, which is known as "zero/low backlash" design.
One significant advantage of the planetary gearbox is its ability to distribute the load evenly among multiple Planet Gears, thereby improving the bearing capacity and stability of the entire system and optimizing the dynamic response performance.
| Design and Selection Factors | Explanation |
|---|---|
| Transmission ratio | The transmission ratio determines the output speed and torque of the gearbox. |
| Load | The load affects the gearbox's torque capacity and service life. |
| Operating temperature range | The operating temperature range affects the gearbox's lubrication and sealing performance. |
| Environmental conditions | The environmental conditions, such as dust, humidity, and corrosiveness, affect the gearbox's sealing and protection. |
| Precision and backlash | The precision and backlash requirements determine the type of gearbox and its manufacturing process and materials. |
| Installation space and configuration | The installation space and configuration affect the gearbox's size and shape. |
The High Precision Planetary Gearbox is widely used in the following fields:
The High Precision Planetary Gearbox is used in applications such as robotics and automation for accurate speed control and position sensing.
The High Precision Planetary Gearbox is used in high-end medical equipment such as CT scanners, MRI machines, and surgical robots for precise motion control and torque amplification.
The High Precision Planetary Gearbox is used in aircraft landing gear systems, flight control systems, and satellite attitude adjustment devices that require high reliability and precision.
The High Precision Planetary Gearbox is used in scientific experimental equipment, precision measuring instruments, and optical tracking systems that require high transmission accuracy.
The High Precision Planetary Gearbox is used in the power steering system of new energy vehicles, the drive unit of electric vehicles, and the transmission system of high-performance racing cars.
The High Precision Planetary Gearbox is used in joint drive parts of industrial robots, service robots, and special operation robots.
The High Precision Planetary Gearbox is used in automated warehouse systems such as lifters, conveyor drives, and AGVs (Automated Guided Vehicles).
We are a professional manufacturer of transmission equipment located in Ningbo, Zhejiang. We operate strictly in accordance with the international quality management system standard ISO9001:2015. Our products have passed the Chinese mandatory CCC certification and the European Community CE certification. Our products are produced according to international IC standards and have reached the advanced level of international similar products.
