WPWX Series Universal Speed Worm Gearboxes

Raydafon Group's WPWX Series Universal Speed Worm Gearboxes deliver precise, high-torque performance for your industrial machinery. Engineered with durable materials and innovative technology, these gearboxes are ideal for robotics, conveyors, and automation systems. They solve torque and speed control issues, offering reliable, long-lasting operation that boosts efficiency and reduces downtime. Stand out with their compact design and universal compatibility, outperforming competitors. Experience seamless integration and enhanced productivity—upgrade your equipment today.

Send Inquiry

Product Description

WPWX Series Universal Speed Worm Gearboxes

We produce WP and RV series worm speed reducers, single, double, and universal speed reducers. The gearboxes can be applied to many industrial areas, such as Metallurgical, mines, lifting, transportation, petrochemical, construction, textile, pharmaceutical, food, environmental, light electric, plastic machine, paper, parking equipment, and so on. Our technical engineers can choose a model for you according to your request, and we also can supply our factory catalog for your reference.

WPWX Worm Gearbox Reducer

Model NO	WPWX
Type	worm gearbox reducer
Ratio	10-100
Color	Blue, gray-green golden, and so on.
Warranty	1 Year
MOQ	1
Custom Service	OEM
Delivery Time	7-30 Days
Trademark	EPT
Transport Package	Standard Export Packing and Wood Pallets Packing
Specification	040-250
Origin	China

Specifications Parameter

Characteristics of WPWX Worm Gearbox

1. The reduction gearbox reducer is a small machine shape, lightweight, without shaft coupling, chain, sprockets, and other transmission parts.2. The input shaft is mounted directly to the machine side and can effectively save space.3. Low cost. Because of the direct installation, without transmission parts, assembly time can be less, as a result. It can reduce the cost.4. Easy installation, stable operation, long service life, and high carrying capacity. Because the direct docking and motor installation can completely prevent contact with transmission parts, there is No need for a safety cover that can ensure safety.

Daily Maintenance of Worm Gearboxes

After the worm gearbox is completed, it is officially put into use, so what routine maintenance work needs to be done during the use of the gearbox? as follows:1. The working place, transmission efficiency, load capacity, and lubricant brand used by the worm gear reducer must comply with the values specified in its specifications.2. The height of the lubricating oil surface of the worm gear reducer head box should be within the height range required by the design when the worm gear is officially put into use. And check the oil supply of each lubricating oil point at any time.3. Regularly check the lubricating oil's impurities, moisture, and viscosity changes. If it is found that the standard is exceeded or not up to par, the lubricant should be treated in time, and the bearing and oil pool should be carefully washed while changing the fat.4. During regular operation of the worm gear reducer, the temperature of the bearing and the oil sump and the noise of the reducer should be checked. If an abnormal situation is found, the cause should be stopped immediately, and it can be used again after the abnormality is eliminated.5. Regularly check the tooth surfaces of the internal gears of the worm gearbox. If there is corrosion, scratches, glued or broken teeth on the tooth surface, it must be shut down immediately and processed.

Packing and Transportation

●Packaging: To ensure the integrity of product appearance, we will choose cartons, wooden pallets, and wooden pallets according to customer needs.●Delivery time: Each reducer is manufactured and tested by strict and fixed procedures to ensure that the quality is correct before leaving the factory and delivery on time.●Transportation mode: We will choose the most suitable mode of transportation for our customers according to the weight and size of the goods. We can also choose the mode of transportation according to the needs of our customers.●Receiving and after-sales service: After receiving the goods, please check whether they are in good condition. We will provide customers with perfect after-sales service. WPWX Series Universal Speed Worm Gearboxes

Company Profile

We handle power transmission products; our lines mainly cover series products in speed reducers, gearboxes, associated electrical motors, and other accessories. Based on their versatile functions, our products can be utilized in many fields: wastewater treatment machines, dredgers, the chemical industry, cranes, metalworking mills, conveyors, the paper industry, the cement industry, cableways, and so on. With excellent quality and reasonable prices, our products enjoy a good reputation from customers and peers worldwide.Furthermore, the R&D investment is increasing annually to meet our customers' new demands better and adapt to the recent tendency of the industry. Depending on the principles of honestly operating and mutual benefit, We sincerely look forward to cooperating with you. WPWX Series Universal Speed Worm Gearboxes

Our Advantages:

1. Reasonable price with excellent quality2. Each one tests carefully3. Clear nameplate4. Reliable package5. High efficiency, smooth running, and low noise6. Best materials make the best performance
