| Model | Normal torque(N.m) | Max. intermittent torque(N.m) | Maximum axial force of output shaft(KN) | Maximum radial force at the midpoint of the output shaftn2*h=30000(KN) | Output shaft | Reduction ratio | |||
| EPT-996A | 10000 | 20000 | 179 | 65 | 2-5/8" hex shaft | 19.33:1 | |||
| * MAX. INPUT SPEED 3000rpm | |||||||||
| * INPUT MOTOR: SAE C FLANGE, DP12/24, Z17, 4 HOLES | |||||||||
| * WITHOUT LUBRICANTS | |||||||||
| * ONLY WITH PRIMER, WITHOUT TOP COAT | |||||||||
| * OUTPUT SHAFT DOWN MOUNTED | |||||||||
Applications:
