Double Direction Thrust Ball Bearings

Double Direction Thrust Ball BearingsDouble direction thrust ball bearings are a common type of thrust ball bearings. Double direction thrust ball bearings can accommodate axial loads and locate a shaft axially in both directions. Double direction thrust ball bearings consist of one shaft washer, two housing washers, and two ball and cage assemblies. The housing washers and ball and cage assemblies of double direction bearings are identical to those used in single direction bearings. Depending on their series and size, thrust ball bearings are fitted with one of the cages, like sheet steel cages or Solid brass window cages.

Product parameter

Boundary dimensions(mm)			Mass(kg)	Bearing NO.
d	D	T		Raydafon
10	32	22	0.076	52202
15	40	26	0.145	52204
20	47	28	0.215	52205
20	47	31.4	0.221	54205
20	52	34	0.291	52305
20	52	37.6	0.303	54305
25	52	29	0.236	52206
25	52	32.6	0.269	54206
25	60	38	0.435	52306
25	60	41.2	0.553	54306
30	62	34	0.371	52207
30	62	37.8	0.749	54207
30	68	44	0.63	52307
30	68	47.2	0.802	54307
30	68	36	0.509	52208
30	68	38.6	0.513	54208
30	78	49	1.02	52308
35	73	37	0.539	52209
35	73	39.6	0.537	54209
35	85	52	1.15	52309

Features of Double Direction Thrust Ball Bearings

- It can accommodate axial loads and carry out axial positioning in two directions.- The structure of two steel ball-cage assemblies can withstand higher axial loads.

Applications of Double Direction Thrust Ball Bearings

Double direction thrust ball bearings are mainly used to bear a part of the axial load and low speed, such as crane hooks, vertical pumps, vertical centrifuges, jacks, low-speed reducers, etc.
