	products type		EPW215			EPW265			EPW315			EPW360			EPW420
	stages		1	2	3	1	2	3	1	2	3	1	2	3	1	2	3
D2	installment hole	4- Φ	14			19			19			24			24
D3	output shaft diameter	Φ h7	50			80			90			110			120
D4	shaft root	Φ	60			100			110			125			140
D6	end surface diameter	Φ h7	140			175			205			225			245
D7	input center bore for motor	Φ H7	114.3	114.3	114.3	180	114.3	114.3	230	180	114.3	250	230	180	300	250	230
D8	input pinion bore	Φ F7	35	35	35	42	35	35	55	42	35	60	55	42	65	60	55
D9	hole circle	Φ	200	200	200	215	200	200	265	215	200	300	265	215	350	300	265
D10	mounting thread depth	4-/8-	M12	M12	M12	M12	M12	M12	M12	M12	M12	M16	M12	M12	M16	M16	M12
Q1	input flange	Φ	□ 175	□ 175	□ 175	250	□ 175	□ 175	300	250	□ 175	350	300	250	400	350	300
L1	key length		70			90			120			150			180
L2	distance from shaft end		5			10			10			10			15
L3	shaft length from spigot		80			110			140			170			210
L4	shaft length form output		85			115			145			175			215
L5	body length		266.5	314.5	352	427	439.5	487.5	483	564	576.5	545	653	734	600	715	823
L7	overall length		411.5	459.5	497	572	614.5	662.5	663	739	781.5	780	863	939	857	990	1073
L9	motor shaft depth		6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5
L10	motor shaft length		83.5	83.5	83.5	93.5	83.5	83.5	116.5	93.5	83.5	145	116.5	93.5	144	145	116.5
L11	installment hole to end surface		70			80			85			115			135
L12	pitch of holes(axial)		180			280			330			350			370
L13	pitch of holes		216			254			310			360			410
L14	foot width		260			310			380			445			500
B1	key width		14			22			25			28			32
H1	key height		53.5			85			95			116			127
Z	orient holes		M12*26			M16*35			M16*35			M16*35			M20*50
HC	height of center		132			160			200			225			250
HD	entire high		239.5			292.5			357.5			405			460
B2	input key slot width		10	10	10	12	10	10	16	12	10	18	16	12	18	18	16
H2	input key slot height		38.3	38.3	38.3	45.3	38.3	38.3	59.3	45.3	38.3	64.4	59.3	45.3	69.4	64.4	59.3

EPW enhancement planetary gear boxes with foot dimensions
