Curved Rack and Pinion Gear

As one of the experienced rack and pinion gears suppliers, we can develop Double Helical Gear Rack, Curved Rack, Pinion Gear, Steel Gear Rack, and Parallel Axis Helical Gear independently that can create new products according to customer needs and ensure the quality of the products meets customer requirements. We have always adhered to this simple concept: to make the best products and let customers rest assured. Since its inception, our company has adhered to a high degree of enthusiasm, down-to-earth, and hard-working service spirit. It can be our tremendous honor to meet your requirements.

Specification of Curved Rack and Pinion Gears

Precision Machining Stainless Steel Curved Rack and Pinion Gear for Robot

Model Number	M1,M1.5,M2,M2.5,M3,M4,M5,M8,M12 etc.
Material	Brass,   C45 steel, Stainless steel, Copper, POM, Aluminum, Alloy, and so on
Surface treatment	Zinc-plated, Nickel plated, Passivation, Oxidation, Anodization,    Geomet, Dacromet, Black Oxide, Phosphatizing, Powder Coating, and   Electrophoresis.
Standard	ISO,   DIN, ANSI, JIS, BS and Non-standard.
Precision	DIN6,DIN7,DIN8,DIN9.
Teeth treatment	Hardened, Milled, or Ground
Tolerance	0.001mm-0.01mm-0.1mm
Finish	shot/sandblast, heat treatment, annealing, tempering, polishing, anodizing, zinc-plated
Items packing	Plastic bag+Cartons Or Wooden Packing
Payment terms	T/T, L/C
Samples	Sample price range from $2 to $100.   sample express request paid by clients
Application	1.   Automatic controlling machine   2. Semi-conductor industry   3. General industry machinery   4. Medical equipment   5. Solar energy equipment   6. Machine tool   7. Parking system   8. High-speed rail and aviation transportation equipment, etc.

The material selection of the arc or curved gear rack and pinion is scientific and reasonable. It fully considers the actual use environment of the project and has good abrasion resistance. The curved gear rack weighs the specific use environment and the material's flow characteristics and processes it after selection. The curved rack and pinions have abrasion resistance and stability after hardening treatment.

Features of Curved Rack and Pinion Gears

• The precision design and processing of a reliable system: the 70° V-shaped guide surface and cylindrical surface in contact with the rollers, and the stop related to other equipment are finished surfaces. High finish, low noise, and linear touch ensure that the guide rail system provides accurate and stable movement.
• High-precision positioning method and servo drive: select the scientific and reasonable positioning method according to different working environments. The highest repeatable positioning accuracy can reach 0.03mm. Imported servo motors drive the power system. It is safe and reliable.
• There are many series connection methods: according to different working environments and specific requirements, it is equipped with chain connection methods such as chains, belts, and linkage rods, which are genuinely scientific and reasonable.
• Intelligent control sets the required motion conditions to automatically and intelligently operate to improve efficiency, reduce labor, and reduce costs.
• Simple and convenient maintenance. The arc guide rack uses the automatic lubrication system for easy operation.
• Wide range of applications: the circulation lines are widely used in various industries, such as electronic assembly, testing, packaging, laser marking, medical treatment, automotive, welding, semi-automatic assembly lines for automatic machines, etc.
• The arc guide rail can be a full circle or composed of two complete 180-degree arc guides, which can be opened and closed. In this way, when the pipe is very long, there is no need to put the arc guide rail from the end and then move it to the required position; or both ends of the long pipe are limited, and there is no place for the arc guide rail to cover up; the arc guide rail can be opened, put it on the tube, and then close it.

Curved Rack and Pinion Gears Design

Applications of Curved Rack and Pinion Gears

Curved rack and pinion systems are used in various applications due to their ability to handle non-linear motion paths.

• 1. Robotics: For precise movement along curved paths.
• 2. Automotive: In steering systems that require non-linear motion.
• 3. Amusement Rides: For guiding vehicles along curved tracks.
• 4. Manufacturing Equipment: For machines that need to transfer objects along curved paths.
• 5. Cranes and Hoists: For lifting mechanisms that move in arcs.
• 6. Theater Stage Equipment: To move sets and props along curved tracks.
• 7. Architectural Designs: In moving elements like sliding doors or dynamic facades.
• 8. Conveyor Systems: For transporting materials around bend.

Curved Rack and Pinion Gears Factory

Our factory has more than ten years of history in the Round Gear Rack industry with rich experience, and that's how we won market reputation. We provide customers with a batch of highly cost-effective curved racks and pinions and bring warm and intimate after-sales service, which has achieved excellent customer satisfaction and loyalty. We have won highly praised foreign customers with the first-class products, excellent service, fast delivery, and the best price. Contact us now! EVER POWER also provides other gear rack products, such as Stainless Steel Gear Rack, Metric Gear Rack, Spur Gear Rack, Helical Gear Rack, Gear Rack for Door Opener,Gear Rack For Greenhouse,etc.
