Raydafon Motor Front Hub Motor: The Perfect Electric Kit for Your E-bike

The P110 Powerful Front Hub Motor is an excellent product for e-bikes, boasting a brushless design, a choice of black or silver, and a rated voltage of 24V/33V/36V. With a rated current range of 6.25A/6.74A/9.16A, a rated output power of 250W, and an impressive efficiency of over 90%, this motor is indeed a powerhouse. It has a rated revolution of 160-260r/min and a lightweight design, weighing only 2.3kg. The packaging includes a carton box with bubble wrap for protection during shipping, and the product can be shipped via Shanghai, Ningbo, or Shenzhen ports.

Specifications of P110 Front Hub Motor for E-bike

Item No.	P110SWXDC36/P110SWXC36
Diameter	113mm±1mm
Width	135±2mm
Brake types	Disc brake / V brake / Roller brake
Outlet position	Under the shaft on the right side
Spoke no.	20H，24H，28H，32H，36H
Spoke types	14g
Controller	Internal
Sensor	Solar pedal sensor
Rated power	250W
Max. power	750W
Max. torque	50N·m
Rated voltage	36V
Rated input current	7.8A
Reduction ratio	1 : 13.5
Grade-ability	＞20%
Efficiency	＞90%
Revolution	160-260RPM
Applicable wheel diameter	14-29inch
Color	Black/Silver
Operation temperature	-20-45℃
Storage temperature	-20-45℃
Waterproof & Dust-proof	IP65
Weight	2.3KG

P110 E-bike Front Hub Motor Dimension

Product Advantages of P110 Front Hub Motor

The P110 Front Hub Motor boasts an array of advantages that make it an ideal choice for e-bikes. Here are six key benefits:

1. Built-in Controller: The motor features an integrated controller, eliminating the need for external controllers and simplifying the e-bike setup.
2. Wireless Pedal Sensor: The wireless pedal sensor provides smooth and responsive motor control, enhancing the riding experience.
3. Easy to Install & Disassemble: The motor is designed for easy installation and removal, making maintenance and replacements a breeze.
4. Max Power & Torque: With a maximum power of 750W and torque exceeding 40N??m, the motor delivers strong and consistent performance, even on challenging terrains.
5. High Efficiency: The motor operates at a high efficiency of over 90%, maximizing the battery life and performance of the e-bike.
6. Wireless Control: The motor supports wireless control, offering convenient and intuitive operation.

We are proud to produce this highly efficient and powerful motor, designed to meet the needs of modern e-bike users.

Applications of P100/P110 Front Hub Motor

The P100/P110 front hub motors are versatile and have a wide range of applications. Here are six common uses:

1. Commuting: The motors provide assistance to commuters, making it easier to cover longer distances and tackle steep hills.
2. Urban Riding: For navigating through busy city streets and congested traffic, these motors offer smooth acceleration and reliable performance.
3. Recreation and Leisure: Whether it's exploring trails or cruising along scenic routes, these motors enhance the overall riding experience.
4. Delivery Services: Many food delivery and courier companies use e-bikes with these motors due to their efficiency and maneuverability in urban environments.
5. Tourism and Sightseeing: These motors are often used in e-bikes for tourism and sightseeing, allowing tourists to explore destinations with ease.
6. Electric Bike Sharing Programs: The P100/P110 motors are commonly used in e-bikes for bike-sharing programs, providing convenient transportation options in urban areas.

How Does the Ebike System P100/P110 Front Hub Motor Work?

The P100/P110 front hub motor is designed specifically for e-bikes. Here's how the e-bike system with this motor works:

1. Power Source: The e-bike system includes a rechargeable battery pack that provides electrical energy to the motor.
2. Motor Controller: The motor controller manages the flow of electricity from the battery to the motor, interpreting input from the rider.
3. Torque Sensor or Throttle: The e-bike system can include a torque sensor, which measures the force applied to the pedals, or a throttle for direct control of the motor's power output.
4. Motor Assistance: When the rider applies force to the pedals or uses the throttle, the motor controller interprets this input and sends the appropriate power to the motor.
5. Front Hub Motor: The motor generates rotational force (torque) that propels the e-bike forward.
6. Power Transmission: The motor's force is transmitted to the wheel through gears integrated into the hub motor, allowing the e-bike to accelerate or maintain speed.
7. Regenerative Braking: Some e-bike systems may have regenerative braking capabilities, converting the kinetic energy of the moving e-bike back into electricity for later use.
8. Display and Control Unit: The e-bike system often includes a display and control unit, providing the rider with information and allowing them to adjust settings.

Choose the Right P100/P110 Front Hub Motor for Ebike System

When choosing the right P100/P110 front hub motor for your e-bike system, consider the following factors:

1. Power and Torque: Consider your riding needs and terrain to choose the right power and torque.
2. Efficiency: Look for a motor that offers high efficiency for better battery life and performance.
3. Compatibility: Ensure the motor is compatible with your e-bike system's voltage and wattage requirements.
4. Wheel Size: The motor should fit the specific wheel size of your e-bike for optimal performance.
5. Weight and Size: Consider the weight and dimensions of the motor as they can affect the overall weight distribution and handling of your e-bike.

Maintenance of P100/P110 Front Hub Motor

Proper maintenance of the P100/P110 front hub motor is crucial for its longevity and performance. Here are some tips:

1. Regular Cleaning: Wipe the motor regularly with a damp cloth to remove dirt, dust, and debris.
2. Inspection: Periodically inspect the motor for any signs of damage or wear and address issues promptly.
3. Lubrication: Some motors may require lubrication for smooth operation. Refer to the manufacturer's guidelines for recommendations.
4. Battery Maintenance: Follow the manufacturer's instructions for battery maintenance, such as proper charging procedures and storage guidelines.
5. Wheel Maintenance: Regularly inspect the wheel for proper alignment, trueness, and spoke tension.
6. Water and Moisture Protection: Avoid excessive moisture and submerging the motor in water.

Why Choose Raydafon's P100/P110 Front Hub Motor for Ebike System?

Established in 1993, Raydafon Electric Technology Co Ltd. is dedicated to the R&D, manufacturing, and worldwide marketing of high-end electric bicycle parts. All our products are designed and developed in-house and protected by a number of domestic and international intellectual property rights. Our products are CE-certified and renowned for their reliable quality, exquisite craftsmanship, and stylish design.We offer a wide range of products, including super-mini wireless motors, super-mini intelligent motors, ALL-IN-ONE front hub motors, P100/P110 front hub motors, water bottle Li-Ion batteries, Wireless buttons, Wireless displays, and more. All our products are suitable for all kinds of bikes and provide electric power support while maximizing bicycles' original appearance and characteristics.We adhere to the enterprise spirit of "Technology Drives Healthy Life" and the business philosophy of "Credit First, Quality First," and constantly develop new products to meet customer needs and market changes. If you are seeking the high-end electrical components of electric bicycles, if you are still worried about traffic jams, or if you would like to contribute to environmental protection, Raydafon sincerely welcomes global distributors to visit and negotiate. We look forward to working with you to jointly promote the development of the electric bicycle industry and contribute to environmental protection. Author: Yjx
