Raydafon P130 ALL-IN-ONE Bicycle Motor

Revolutionize your biking experience with the Raydafon P130 ALL-IN-ONE Front Hub Motor. This innovative product incorporates a built-in lithium battery and wireless controller, offering an efficient and seamless ride. Designed with a brushless motor, this front hub bike motor is available in stylish black and silver.

P130 ALL-IN-ONE Front Hub Motor Specification:

Item No.	P130SWXDC30/P130SWXC30
Diameter	143mm??1mm
Width	100??2mm
Brake types	Disc brake/ V brake
Outlet position	No cable
Spoke no.	20H??24H??28H??32H??36H
Spoke types	14g
Controller	Internal
Sensor	Wireless pedal sensor
Battery	7Ah
Rated power	250W
Max. power	300W
Max. torque	30N??m
Rated voltage	30V
Rated input current	8.3A
Reduction ratio	1 : 13.5
Grade-ability	??20%
Efficiency	??90%
Revolution	160-260RPM
Applicable wheel diameter	14-29inch
Color	Black/Silver
Noise	??50dB
Operation temperature	-20-45??
Storage temperature	-20-45??
Waterproof & Dust-proof	IP65
Weight	2.6KGS

P130 ALL-IN-ONE Front Hub Motor Dimension:

Advantages of the Raydafon P130 ALL-IN-ONE Front Hub Motor

The Raydafon P130 ALL-IN-ONE Front Hub Motor is packed with several unique features that set it apart from other products in the market:

• • Built-in 7Ah battery and controller: The motor comes with an integrated 7Ah battery and controller, eliminating the need for separate components and making it compact and easy to handle.
  • Wireless pedal sensor: This provides more convenience and a better riding experience as it eliminates the need for wires that can get tangled or damaged.
  • Supports extended-range battery: The motor supports the use of an extended-range battery, allowing for longer rides without the need for frequent recharging.
  • Lightweight: Weighing just 2.6kg, this motor doesn't add significant weight to your bicycle, ensuring a comfortable ride.

• Wireless control: The Bluetooth button/display controller provides wireless control, adding to the convenience and ease of use.
• Easy to install & disassemble: You can easily install or remove this motor, making it suitable for various types of bicycles.

At Raydafon, we are committed to providing high-quality products that meet our customers' needs. With our advanced production capabilities, we can produce this exceptional front hub motor that will transform your biking experience.

Applications of the ALL-IN-ONE Front Hub Motor

Our ALL-IN-ONE Front Hub Motor system for e-bikes has a wide range of applications:

• • Commuting: This system is popular among commuters who want to incorporate the benefits of electric assistance into their daily travels.
  • Urban Transportation: E-bikes equipped with ALL-IN-ONE Front Hub Motors provide an eco-friendly alternative to traditional modes of transportation like cars or motorcycles.
  • Recreation and Leisure: Whether it's exploring scenic trails, going on off-road adventures, or simply enjoying a leisurely ride, the electric assistance provided by the system enhances the overall experience.
  • Delivery Services: With the growing demand for efficient and sustainable delivery services, e-bikes equipped with ALL-IN-ONE Front Hub Motors have become a popular choice for last-mile deliveries.
  • Bike-Sharing Programs: The compact and user-friendly nature of the ALL-IN-ONE Front Hub Motor system makes it suitable for bike-sharing programs.

How Does the Ebike System ALL-IN-ONE Front Hub Motor Work?

The ALL-IN-ONE front hub motor system for e-bikes combines several components into a single unit:

• • Motor: The front hub motor is located in the front wheel hub. It consists of a brushless electric motor that generates torque to propel the bicycle forward.
  • Battery: The battery supplies power to the motor and is responsible for storing and providing the electrical energy needed for propulsion.
  • Controller: The controller acts as the brain of the system, managing the flow of electricity between the battery and the motor.
  • Power delivery: When the rider activates the electric assistance, a signal is sent to the controller, which then determines the level of assistance required and sends the appropriate amount of current from the battery to the motor.

• Propulsion: As the current flows into the motor, it creates a magnetic field that interacts with the magnets in the motor, which propels the bicycle forward.
• Control settings: The ALL-IN-ONE front hub motor system often offers different control settings to suit the rider's preferences.

Choosing the Right ALL-IN-ONE Front Hub Motor for Your Ebike System

When choosing the right ALL-IN-ONE front hub motor for your e-bike system, consider the following factors:

• Power and torque: Consider your riding needs and terrain to choose a motor with the right power and torque.
• Battery capacity: The battery capacity directly affects the range of your e-bike. Consider the distance you typically ride and choose a battery capacity that meets your requirements.
• Voltage and current: Ensure that the motor and battery voltage and current specifications match to ensure proper operation and avoid damage to the components.
• Wheel size: Check the compatibility of the front hub motor with your e-bike's wheel size.
• Weight and balance: Consider the weight of the front hub motor system and ensure that the weight distribution remains balanced between the front and rear of the bike.
• Installation compatibility: Check the compatibility of the front hub motor system with your bike's fork and dropout spacing.

Maintenance of the ALL-IN-ONE Front Hub Motor

Proper maintenance of the ALL-IN-ONE front hub motor for your e-bike system is essential:

• Regular cleaning: Clean the front hub motor and the surrounding area regularly to prevent the buildup of dirt, dust, and debris.
• Battery maintenance: Take care of the e-bike's battery according to the manufacturer's instructions.
• Check electrical connections: Periodically inspect the electrical connections between the motor, controller, and battery.
• Tire pressure and wheel alignment: Maintain the appropriate tire pressure and check the wheel alignment.
• Brake system maintenance: Regularly inspect and adjust the brakes to ensure they are functioning properly.
• Lubrication: Apply lubricant to the moving parts of the front hub motor system, such as the bearings and gears.
• Protect from moisture: Avoid exposing the front hub motor and electrical components to excessive moisture.

Why Choose Raydafon's ALL-IN-ONE Front Hub Motor for Ebike System?

Established in 1993, Raydafon Electric Technology Co Ltd. is dedicated to the R&D, manufacturing, and worldwide marketing of high-end electric bicycle parts. We offer high-quality products, CE-certified and protected by independent intellectual property rights. Our products such as super-mini wireless motors, super-mini intelligent motors, All-IN-ONE motors, and others are suitable for all kinds of bikes.As a company, we adhere to the enterprise spirit of "Technology Drives Healthy Life," adhere to the business philosophy of "Credit First, Quality First," and constantly develop new products to meet customer needs and market changes. Our commitment to quality is evident in our advanced production capabilities and robust quality management system. We offer ODM and OEM services, customized to your specific requirements. Our after-sales service is available in Germany and China, for your convenience. We sincerely welcome global distributors to visit and negotiate. We look forward to working with you to jointly promote the development of the electric bicycle industry and contribute to environmental protection.Author: Yjx
