Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin
  • Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head PinRegular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin

Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin

Discover Raydafon Group's Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin: a durable, high-strength solution for industrial and heavy-duty applications. Crafted with drop-forged steel for superior reliability and safety, it's ideal for engineers, construction workers, and manufacturers needing secure lifting or towing. Experience peace of mind with enhanced efficiency and reduced downtime, setting it apart with its rivetless design for easy maintenance. Choose Raydafon Group for trusted quality that elevates your projects.
Send Inquiry
Product Description

Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin

Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin
Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin
REGULAR TYPE Regular Type is furnished with only the T-head pins heat treated. These pins are symmetrical and may be reversed when worn.
A-L CHAIN NO.
PITCH IN INCHES
LINKS PER10 FEET
WEIGHT PER FOOT LBS.
AVERAGE ULTIMATE STRENGTH—LBS.Head Treated Steel*
CHAIN CONSTRUCTION
3.031" PITCH CHAIN
X348
3.031
40
2.2
24,000
Special Pin
4.031" PITCH CHAIN
X458
4.031
30
3.2
48,000
Special Pin
468
4.031
30
7.5
70,000
Special Pin
6.031" PITCH CHAIN
X658
6.031
20
2.6
48,000
Special Pin
X678
6.031
20
6.7
85,000
Special Pin
698
6.031
20
11.4
130,000
Special Pin
9.031" PITCH CHAIN
998
9.031
13.3
9.0
130,000
Special Pin
9118
9.031
13.3
16.0
220,000
Special Pin
9148
9.031
13.3
27.0
300,000
Special Pin
3.031" PITCH CHAIN
S348
3.031
40
2.4
24,000
Riveted
4.031" PITCH CHAIN
S458
4.031
30
3.5
48,000
Riveted
4.031" PITCH CHAIN
S468
4.031
30
7.9
80,000
Riveted
9.031" PITCH CHAIN
S9118
9.031
13.3
20.4
220,000
Riveted
Rivet free fall forging chains are considered to be one of the most powerful chains ever made and are widely used in many industries. Since the material does not tend to pack in its open structure, rivetless drop forged chains are widely used in flying conveyors. Its design allows both horizontal and vertical running on irregular routes, making it particularly suitable for trolley delivery services.The chain features include maximum strength without excessive weight and resistance to elongation even after extensive handling.Regular Type Rivetless Drop Forged Chain Bar Loop Chains With T Head Pin
